流量 |
揚程 |
轉速 |
功率（KW） |
效率 |
允許吸上 |
汽蝕 |
重量 |
||
|
型號 |
級數 |
m³/h |
L/S |
(m) |
(r/min) |
軸功率 |
電機功率 |
(%) |
真空高度 (m) |
余量 (m) |
(kg) |
|
|
2 |
72 90 108 |
20 25 30 |
46 43.2 40 |
1450 |
12.89 14.32 15.59 |
22 |
70 74 75.5 |
7.2 6.8 6.2 |
2.9 3.4 4.1 |
475 |
|
3 |
72 90 108 |
20 25 30 |
69 64.8 60 |
1450 |
19.34 21.48 23.39 |
30 |
70 74 75.5 |
7.2 6.8 6.2 |
2.9 3.4 4.1 |
555 |
|
|
4 |
72 90 108 |
20 25 30 |
92 86.4 80 |
1450 |
25.79 28.63 31.18 |
45 |
70 74 75.5 |
7.2 6.8 6.2 |
2.9 3.4 4.1 |
640 |
|
|
5 |
72 90 108 |
20 25 30 |
115 108 100 |
1450 |
32.23 35.79 38.98 |
55 |
70 74 75.5 |
7.2 6.8 6.2 |
2.9 3.4 4.1 |
726 |
|
|
6 |
72 90 108 |
20 25 30 |
138 129.6 120 |
1450 |
38.67 42.95 46.78 |
75 |
70 74 75.5 |
7.2 6.8 6.2 |
2.9 3.4 4.1 |
840 |
|
|
125TSWA |
7 |
72 90 108 |
20 25 30 |
161 151.2 140 |
1450 |
45.12 50.11 54.57 |
75 |
70 74 75.5 |
7.2 6.8 6.2 |
2.9 3.4 4.1 |
923 |
|
8 |
72 90 108 |
20 25 30 |
184 172.8 160 |
1450 |
51.57 57.27 62.37 |
90 |
70 74 75.5 |
7.2 6.8 6.2 |
2.9 3.4 4.1 |
1008 |
|
|
9 |
72 90 108 |
20 25 30 |
207 194.4 180 |
1450 |
58.02 64.43 70.16 |
90 |
70 74 75.5 |
7.2 6.8 6.2 |
2.9 3.4 4.1 |
1093 |
|
|
10 |
72 90 108 |
20 25 30 |
230 216 200 |
1450 |
64.46 71.59 77.96 |
90 |
70 74 75.5 |
7.2 6.8 6.2 |
2.9 3.4 4.1 |
1178 |
|
|
|
2 |
119 155 191 |
33 43 53 |
65 60 54.9 |
1450 |
29.03 32.91 36.19 |
45 |
72.6 77 78.8 |
8 7.7 6.6 |
2.1 2.5 3.5 |
522 |
|
3 |
119 155 191 |
33 43 53 |
97.5 90 82.4 |
1450 |
43.55 49.37 54.29 |
75 |
72.6 77 78.8 |
8 7.7 6.6 |
2.1 2.5 3.5 |
604 |
|
|
4 |
119 155 191 |
33 43 53 |
130 120 109.8 |
1450 |
58.06 65.82 72.39 |
90 |
72.6 77 78.8 |
8 7.7 6.6 |
2.1 2.5 3.5 |
686 |
|
|
5 |
119 155 191 |
33 43 53 |
162.5 150 137.2 |
1450 |
72.58 82.28 90.49 |
110 |
72.6 77 78.8 |
8 7.7 6.6 |
2.1 2.5 3.5 |
768 |
|
|
150TSWA |
6 |
119 155 191 |
33 43 53 |
195 180 164.7 |
1450 |
87.1 98.74 108.58 |
132 |
72.6 77 78.8 |
8 7.7 6.6 |
2.1 2.5 3.5 |
850 |
|
7 |
119 155 191 |
33 43 53 |
227.5 21O 192.1 |
1450 |
101.61 115.19 126.68 |
132 |
72.6 77 78.8 |
8 7.7 6.6 |
2.1 2.5 3.5 |
930 |
|
|
8 |
119 155 191 |
33 43 53 |
260 240 219.6 |
1450 |
116.12 131.65 144.78 |
160 |
72.6 77 78.8 |
8 7.7 6.6 |
2.1 2.5 3.5 |
1013 |
|
|
9 |
119 155 191 |
33 43 53 |
292.5 270 247.O |
1450 |
130.64 148.10 162.87 |
200 |
72.6 77 78.8 |
8 7.7 6.6 |
2.1 2.5 3.5 |
1095 |
|
